XCMG
XGA16K-AS
498 lb (226 kg)
Capacidad de plataforma
Documentos
Especificaciones completas
| 1st boom luffing range | 0~65 ° | ↗ |
| 2nd boom luffing range | -11~75 ° | ↗ |
| Max. Grade Ability | 45% | ↗ |
| Max. Load Capacity | 226(unlimited)/320(limited) kg | ↗ |
| Max. Platform Height | 48.0 ft (14.6 m) | ↗ |
| Max. Travel Speed | 5.5（stowed)/1（raised or extended) km/h | ↗ |
| Max. Working Height | 54.6 ft (16.6 m) | ↗ |
| Max. Working Range | 28.9 ft (8.8 m) | ↗ |
| Rotation Angle of Turntable | 355 ° | ↗ |
| Total Weight | 16,755 lb (7,600 kg) | ↗ |
| Wheel Base | 92.9 in (2,360 mm) | ↗ |
Cada valor se rastrea hasta los datos publicados por el fabricante. ↗ abre la fuente.
