Matco Tools
AC9028
Spécifications complètes
| Air Supply Gauge | 0psi-300psi | ↗ |
| Assist Arms/Tools | 4 Powered | ↗ |
| Bead Lifting System | Manual Tool Bar | ↗ |
| Bead Loosening System | Foot Powered Side Shovel | ↗ |
| Chassis Footprint | 79"W x 76"D x 86"H | ↗ |
| Clamps | Steel w/ Plastic Covers | ↗ |
| Color (Matco Standard) | Red | ↗ |
| Diameter (Min/Max) | 47" | ↗ |
| Drive System | Electric | ↗ |
| Electric Drive System | 2 HP electric motor, 110V 60Hz, 30 A (110psi-175psi, 5 scfm required for cylinders) | ↗ |
| Height Of Table To Floor | 26" | ↗ |
| Inflation Gauge | 60psi | ↗ |
| Inflation Guard | N/A | ↗ |
| Mount/Demount | Tilt Back | ↗ |
| Operation | 1st loosen bead, 2nd mount/demount | ↗ |
| Pressure Limiter | Standard | ↗ |
| Protectors | Standard | ↗ |
| Recommended Work Area | 7' x 10' | ↗ |
| Rim Diameter | 10"-28" external | ↗ |
| Rim Width | 16" | ↗ |
| Robo-Arm | Yes | ↗ |
| Self Calibrating | N/A | ↗ |
| Shipping Weight | 988 lbs. | ↗ |
| Table Shape | X Shape | ↗ |
| Tire Diameter | 47" | ↗ |
| Tool Head Offset | Manual | ↗ |
| Water Filter/Lubrication Or Oil Injector | Oil Injector | ↗ |
| Weight | 988 lbs. | ↗ |
| Wheel Clamping Method | Rim Clamp | ↗ |
| Wheel Handled | Car and Light Truck,Alloy and Steel | ↗ |
| Wheel Lift | Optional | ↗ |
Chaque valeur est retracée jusqu’aux données publiées par le fabricant. ↗ ouvre la source.
