JLG
ERT4769
13,655 lb (6,194 kg)
Operating weight
800 lb (363 kg)
Platform capacity
47 ft (14.3 m)
Working height
5.6 km/h
drive speed lowered
2 WD AC Electric
drive type
30%
gradeability
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Operating weight | Platform capacity | Working height |
|---|---|---|---|---|
| Snorkel S6940RTE | 99% | - | 800 lb (363 kg) | 46 ft (14.0 m) |
| Snorkel S6947RTE | 94% | - | 800 lb (363 kg) | 53 ft (16.2 m) |
| Snorkel S3970RT | 94% | - | 769 lb (349 kg) | 43 ft (13.1 m) |
| MEC 4069ERT | 92% | 11,244 lb (5,100 kg) | 800 lb (363 kg) | 45.9 ft (14.0 m) |
| MEC 4069RT | 92% | 11,001 lb (4,990 kg) | 800 lb (363 kg) | 45.9 ft (14.0 m) |
| Genie GS-4069R | 92% | 10,393 lb (4,714 kg) | - | 46.9 ft (14.3 m) |
Documents
Full specifications
| Gradeability | 35 | ↗ |
| Machine Height | 9–ft 1–in ft-in | ↗ |
| Machine Width | 69.3- in | ↗ |
| Max Platform Capacity | 800 lb (363 kg) | ↗ |
| Max Platform Height | 47–ft 0–in ft-in | ↗ |
| Max Tilt Rating | 2.5 Degree | ↗ |
| Number of Occupants | 3 | ↗ |
| Platform Capacity | 800 lb (363 kg) | ↗ |
| Platform Extension Capacity | 300 lb (136 kg) | ↗ |
| Platform Height | 47- ft | ↗ |
| Turning Radius | 6–ft 11–in ft-in | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
