JLG
RT3394
31 hp
Engine power
11,843 lb (5,372 kg)
Operating weight
2,249 lb (1,020 kg)
Platform capacity
33 ft (10.1 m)
Working height
4.8 km/h
drive speed lowered
83.3 L
fuel tank capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Engine power | Operating weight | Platform capacity |
|---|---|---|---|---|
| Dingli JCPT3225HRT | 98% | - | - | 2,205 lb (1,000 kg) |
| Dingli JCPT3225RT | 98% | - | - | 2,205 lb (1,000 kg) |
| Dingli JCPT2825RT | 91% | - | - | 2,205 lb (1,000 kg) |
| Dingli JCPT2825HRT | 91% | - | - | 2,205 lb (1,000 kg) |
| Genie GS-3268 RT | 91% | - | - | - |
| Snorkel S9033RT | 87% | - | - | 2,500 lb (1,134 kg) |
Documents
Full specifications
| Drive Speed (Lowered) | 3.5 mph | ↗ |
| Gradeability | 45 | ↗ |
| Machine Height | 9–ft 1–in ft-in | ↗ |
| Machine Length | 12- ft | ↗ |
| Machine Width | 7- ft | ↗ |
| Max Platform Capacity | 2,250 lb (1,021 kg) | ↗ |
| Max Platform Height | 33–ft 0–in ft-in | ↗ |
| Number of Occupants | 6 | ↗ |
| Platform Capacity | 2,250 lb (1,021 kg) | ↗ |
| Platform Extension Capacity | 500 lb (227 kg) | ↗ |
| Platform Height | 33- ft | ↗ |
| Turning Radius | 8–ft 10–in ft-in | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
