JLG
RT4394
31 hp
Engine power
15,243 lb (6,914 kg)
Operating weight
1,499 lb (680 kg)
Platform capacity
43 ft (13.1 m)
Working height
5.6 km/h
drive speed lowered
83.3 L
fuel tank capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Engine power | Operating weight | Platform capacity |
|---|---|---|---|---|
| Genie GS-4390 | 86% | 48 hp | 13,296 lb (6,031 kg) | 1,499 lb (680 kg) |
| MEC 3084RT Speed Level | 85% | - | - | 1,499 lb (680 kg) |
| Genie GS-5390 | 83% | 48 hp | 16,826 lb (7,632 kg) | 1,499 lb (680 kg) |
| Genie GS-3268 RT | 82% | - | - | - |
| Snorkel SL26RT | 80% | - | 7,826 lb (3,550 kg) | 1,499 lb (680 kg) |
| MEC 4069RT | 79% | 25 hp | 11,133 lb (5,050 kg) | 800 lb (363 kg) |
Documents
Full specifications
| Drive Speed (Lowered) | 3.5 mph | ↗ |
| Gradeability | 45% | ↗ |
| Machine Height | 9 ft 10 in | ↗ |
| Machine Length | 12 ft (3.7 m) | ↗ |
| Machine Width | 7 ft (2.1 m) | ↗ |
| Max Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Max Platform Height | 43 ft 0 in | ↗ |
| Number of Occupants | 6 | ↗ |
| Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Platform Extension Capacity | 500 lb (227 kg) | ↗ |
| Platform Height | 43 ft (13.1 m) | ↗ |
| Turning Radius | 8 ft 10 in | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
