JLG
RT5394
31 hp
Engine power
17,110 lb (7,761 kg)
Operating weight
1,499 lb (680 kg)
Platform capacity
53 ft (16.2 m)
Working height
5.6 km/h
drive speed lowered
83.3 L
fuel tank capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Engine power | Operating weight | Platform capacity |
|---|---|---|---|---|
| Snorkel S9043RT | 96% | - | - | 1,499 lb (680 kg) |
| Snorkel S9053RT | 95% | - | - | 1,499 lb (680 kg) |
| MEC 6092RT Ultra Deck | 84% | - | - | 1,199 lb (544 kg) |
| Genie GS-5390 | 81% | 48 hp | 16,826 lb (7,632 kg) | 3,307 lb (1,500 kg) |
| Skyjack SJB-60TB | 81% | - | 23,440 lb (10,632 kg) | - |
| Dingli JCPT3730HRT | 80% | - | - | 1,653 lb (750 kg) |
Documents
Full specifications
| Drive Speed (Lowered) | 3.5 mph | ↗ |
| Gradeability | 40 | ↗ |
| Machine Height | 10 ft 1 in | ↗ |
| Machine Length | 16- ft | ↗ |
| Machine Width | 7- ft | ↗ |
| Max Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Max Platform Height | 53 ft 0 in | ↗ |
| Max Tilt Rating | 1.5 Degree | ↗ |
| Number of Occupants | 6 | ↗ |
| Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Platform Extension Capacity | 500 lb (227 kg) | ↗ |
| Platform Height | 53- ft | ↗ |
| Turning Radius | 9 ft 0 in | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
