Louisville Ladder
DXL3020-40PT
661 lb (300 kg)
Load capacity
30.5 ft (9.3 m)
Max height
Documents
Full specifications
| ANSI | Certified | ↗ |
| Certified | OSHA | ↗ |
| Closed Depth | 7 | ↗ |
| Closed Height | 247.5 | ↗ |
| Closed Volume (cu. ft.) | 18.548 | ↗ |
| Closed Width (in) | 18.5 | ↗ |
| Duty Rating | Type IA | ↗ |
| Inside Width Base (in) | 15.525 | ↗ |
| Inside Width Fly (in) | 14.375 | ↗ |
| Load Capacity (lbs) | 300 | ↗ |
| Material | Fiberglass | ↗ |
| Max. Extended Length (ft) | 35 | ↗ |
| Maximum Standing Height (in) | 30.5 | ↗ |
| Number of Steps | 40 | ↗ |
| Open Depth (in) | 7 | ↗ |
| Open Height (in) | 426 | ↗ |
| Open Volume (cu. ft.) | 31.93 | ↗ |
| Open Volume (cu. m.) | 0.9 | ↗ |
| Open Width (in) | 18.5 | ↗ |
| Outside Width Base (in) | 17.625 | ↗ |
| Outside Width Fly (in) | 16.625 | ↗ |
| Rail Depth (in) | 3.25 | ↗ |
| Rung Type | D-rung | ↗ |
| SKU | DXL3020-40PT | ↗ |
| Section Length (ft) | 20 | ↗ |
| Size | 40 | ↗ |
| Step Depth | 1.5 | ↗ |
| Style | Standard | ↗ |
| Total Length (ft) | 40 | ↗ |
| Weight | 97 | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
