Louisville Ladder
DXL3030-10
661 lb (300 kg)
Load capacity
10 ft (3.0 m)
Max height
Documents
Full specifications
| Closed Depth | 10 | ↗ |
| Closed Height | 124 | ↗ |
| Closed Volume (cu. ft.) | 21.99586317 | ↗ |
| Closed Width (in) | 31 | ↗ |
| Duty Rating | Type IA | ↗ |
| Load Capacity (lbs) | 300 | ↗ |
| Material | Fiberglass | ↗ |
| Maximum Reach (in) | 170 | ↗ |
| Maximum Standing Height (in) | 91 | ↗ |
| Number of Steps | 9 | ↗ |
| Open Depth (in) | 83 | ↗ |
| Open Height (in) | 114.375 | ↗ |
| Open Volume (cu. ft.) | 15.64 | ↗ |
| Open Volume (cu. m.) | 4.88 | ↗ |
| Open Width (in) | 31.375 | ↗ |
| Rung Type | Mega Step | ↗ |
| SKU | DXL3030-10 | ↗ |
| Size | 10 | ↗ |
| Step Depth | 3 | ↗ |
| Style | Standard | ↗ |
| Top Width Closed (in) | 13.25 | ↗ |
| Weight | 54 | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
