Mitsubishi
FB25ACN
10.8 ft (3.3 m)
Lift height
5,512 lb (2,500 kg)
Load capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Lift height | Load capacity |
|---|---|---|---|
| Nissan PFD40M-PFD70M | 99% | 11 ft (3.4 m) | 5,501 lb (2,495 kg) |
| Unicarriers PFD40M-PFD70M | 99% | 10.9 ft (3.3 m) | 5,501 lb (2,495 kg) |
| Nissan PF30N-PF70N | 95% | 10.8 ft (3.3 m) | 5,000 lb (2,268 kg) |
| Unicarriers PF30N-PF70N | 95% | 10.8 ft (3.3 m) | 5,000 lb (2,268 kg) |
| XCMG FD30T | 87% | 9.8 ft (3.0 m) | 6,614 lb (3,000 kg) |
| XCMG XCF305K | 87% | 9.8 ft (3.0 m) | 6,614 lb (3,000 kg) |
Documents
Full specifications
| Acceleration time (10 metres) with/without load | 4.1 / 3.8 s | ↗ |
| Axle loading with maximum load, front/rear (simplex mast, lowest lift height) | 6296/788 kg | ↗ |
| Axle loading without load, front/rear (simplex mast, lowest lift height) | 2256/2328 kg | ↗ |
| Battery to DIN 43 531/35/36 A/B/C/no | 43536A | ↗ |
| Battery voltage/capacity at 5-hour discharge | 80 / 560 - 620 V/Ah | ↗ |
| Battery weight | 3,435 lb (1,558 kg) | ↗ |
| Drive motor capacity (60 min. short duty) | 2 × 8 kW | ↗ |
| Fork carriage to DIN 15 173 A/B/no | 2A | ↗ |
| Fork carriage width | 39.4 in (1,000 mm) | ↗ |
| Fork dimensions (thickness, width, length) | 40 × 100 × 1070 mm | ↗ |
| Free lift (see tables) | 3.9 in (100 mm) | ↗ |
| Gradeability, with/without load | 15 / 25 % | ↗ |
| Ground clearance at centre of wheelbase, with load (forks lowered) | 4.8 in (122 mm) | ↗ |
| Ground clearance under mast, with load | 4.1 in (105 mm) | ↗ |
| Height to top of overhead guard | 88.2 in (2,240 mm) | ↗ |
| Height with mast extended | 171 in (4,355 mm) | ↗ |
| Height with mast lowered (see tables) | 84.4 in (2,145 mm) | ↗ |
| Length to fork face (includes fork thickness) | 94.1 in (2,389 mm) | ↗ |
| Lift height (see tables) | 130 in (3,300 mm) | ↗ |
| Lift motor output at 15% duty factor | 20.8 kW | ↗ |
| Lifting speed, with/without load | 0.5 / 0.65 m/s | ↗ |
| Load capacity | 5,512 lb (2,500 kg) | ↗ |
| Load centre distance | 19.7 in (500 mm) | ↗ |
| Load distance, axle to fork face (forks lowered) | 18.7 in (476 mm) | ↗ |
| Lowering speed, with/without load | 0.55 / 0.5 m/s | ↗ |
| Manufacturer's model designation | FB25ACN | ↗ |
| Mast tilt, forwards/backwards | 6 / 8 ° | ↗ |
| Maximum drawbar pull, with/without load (5 min short duty) | 15800 / 16200 | ↗ |
| Maximum gradeability, with/without load | 23 / 38 s | ↗ |
| Minimum distance between centres of rotation | 6.3 in (160 mm) | ↗ |
| Oil volume for attachments | 30 L/min | ↗ |
| Operating pressure for attachments | 185 bar | ↗ |
| Operator type: pedestrian, (operator)-standing, -seated | Seated | ↗ |
| Overall length | 136 in (3,459 mm) | ↗ |
| Overall width | 46.9 in (1,190 mm) | ↗ |
| Power source: (battery, diesel, LP gas, petrol) | Battery | ↗ |
| Rated drawbar pull, with/without load | 9300 / 9700 N | ↗ |
| Seat height | 44.5 in (1,130 mm) | ↗ |
| Service brakes (mechanical /hydraulic /electric /pneumatic) | Hydraulic | ↗ |
| Sound pressure level at the driver's seat | 65 dB (A) | ↗ |
| Tow coupling height | 15.6 in (395 mm) | ↗ |
| Towing coupling, type DIN 15170 | DIN 15170 - H | ↗ |
| Track width (center of tyres), drive side | 38.8 in (985 mm) | ↗ |
| Track width (center of tyres), load side | 38.2 in (970 mm) | ↗ |
| Travel speed, with/without load | 20 / 20 km/h | ↗ |
| Truck weight without load, with maximum battery weight | 10,106 lb (4,584 kg) | ↗ |
| Turning circle radius | 75.6 in (1,920 mm) | ↗ |
| Type of drive control | AC electronic | ↗ |
| Tyre dimensions, front | 23 × 9 - 10 | ↗ |
| Tyre dimensions, rear | 18 × 7 - 8 | ↗ |
| Tyres: V=solid, L=pneumatic, SE=solid pneumatic - front/rear | SE | ↗ |
| Wheelbase | 62.4 in (1,585 mm) | ↗ |
| Working aisle width (Ast) with 800 × 1200 mm pallets, load lengthwise, platform up/down | 142 in (3,605 mm) | ↗ |
| Working aisle width (Ast3) with 800 × 1200 mm pallets, load lengthwise, platform up/down | 150 in (3,815 mm) | ↗ |
| Working aisle width with 1000 × 1200 mm pallets, crosswise | 144 in (3,660 mm) | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
