SkyTrak
6042
74 hp
Engine power
42.3 ft (12.9 m)
Lift height
6,001 lb (2,722 kg)
Load capacity
19,101 lb (8,664 kg)
Operating weight
106 L
fuel tank capacity
6,001 lb (2,722 kg)
lift capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Engine power | Lift height | Load capacity |
|---|---|---|---|---|
| Sany STH634A | 100% | 74 hp | - | 5,999 lb (2,721 kg) |
| Manitou MTA 642 | 100% | 74 hp | 42.5 ft (13.0 m) | 6,001 lb (2,722 kg) |
| Skyjack SJ643 TH | 98% | 74 hp | - | 6,001 lb (2,722 kg) |
| Caterpillar TL642D | 96% | - | 42 ft (12.8 m) | 6,499 lb (2,948 kg) |
| Gehl RS6-34 GEN:3 | 94% | 74 hp | 34.2 ft (10.4 m) | 6,001 lb (2,722 kg) |
| JLG 6042 | 94% | 74 hp | 42.3 ft (12.9 m) | 6,001 lb (2,722 kg) |
Documents
Full specifications
| Axle Front | High Bias, Limited Slip | ↗ |
| Axle Rear | Oscillating | ↗ |
| Boom Speed Extending Out | 13.8 s | ↗ |
| Boom Speed Retracting In | 12 s | ↗ |
| Capacity Maximum Lift Height | 6,000 lb (2,722 kg) | ↗ |
| Capacity Maximum Reach | 1,200 lb (544 kg) | ↗ |
| Engine Horsepower | 74 hp | ↗ |
| Engine Manufacturer | Deutz | ↗ |
| Engine Type Diesel | TCD2.9 L4 | ↗ |
| Frame Leveling | 10 deg | ↗ |
| Fuel Tank Capacity Diesel | 28 gal (US) | ↗ |
| Ground Clearance | 15.1 in (38.4 cm) | ↗ |
| HPRPM | 1400 rpm | ↗ |
| Is Current Model | false | ↗ |
| Lift Speed Down | 11.3 s | ↗ |
| Lift Speed Up | 13.3 s | ↗ |
| Machine Height | 99.8 in (253 cm) | ↗ |
| Machine Length | 236 in (599 cm) | ↗ |
| Machine Weight | 19,100 lb (8,664 kg) | ↗ |
| Machine Wheelbase | 122 in (310 cm) | ↗ |
| Machine Width | 95 in (241 cm) | ↗ |
| Max Travel Speed | 22 ft/s | ↗ |
| Maximum Lift Height | 508 in (1,290 cm) | ↗ |
| Maximum Reach | 354 in (899 cm) | ↗ |
| Outriggersor Stabilizers Info | false | ↗ |
| Rated Capacity | 6,000 lb (2,722 kg) | ↗ |
| Service Brake Type | Wet Multi-Disc | ↗ |
| Tire Size Type | 15-19.5 | ↗ |
| Transmission | Hydrostatic | ↗ |
| Turning Radius Outside | 151 in (384 cm) | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
