Wacker Neuson
EW100
16.3 ft (5.0 m)
Max dig depth
24,780 lb (11,240 kg)
Operating weight
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Max dig depth | Operating weight |
|---|---|---|---|
| JCB Hydradig 110W | 94% | 14.5 ft (4.4 m) | 24,361 lb (11,050 kg) |
| Hitachi ZX135W-7 | 85% | 15.6 ft (4.8 m) | 33,510 lb (15,200 kg) |
| Hitachi ZX150W-7 | 84% | 16.6 ft (5.1 m) | 35,825 lb (16,250 kg) |
| Hitachi ZX155W-7 | 80% | 17.5 ft (5.3 m) | 37,258 lb (16,900 kg) |
| Develon DX140W-7K | 79% | 14 ft (4.3 m) | 34,670 lb (15,726 kg) |
| Hitachi ZX175W-7 | 78% | 17.5 ft (5.3 m) | 39,132 lb (17,750 kg) |
Documents
Full specifications
| Bore | 3.1 in (80 mm) | ↗ |
| Break Out Force Lift Arm | 44 kN | ↗ |
| Breakout force | 73.3 kN | ↗ |
| Chassis Operating pressure | 440 bar | ↗ |
| Cylinder | 4 | ↗ |
| Cylinder capacity | 2,799 cm³ | ↗ |
| Digging depth (max.) | 196 in (4,968 mm) | ↗ |
| Effective power | 55.4 KW | ↗ |
| Flow rate | 180 l/min | ↗ |
| Height | 117 in (2,980 mm) | ↗ |
| Inclined position max. | 30 ° | ↗ |
| Length | 264 in (6,707 mm) | ↗ |
| Maximum torque | 300 Nm | ↗ |
| Nominal Engine speed | 1,900 1/min | ↗ |
| Operating pressure hydraulics | 300 bar | ↗ |
| Operating weight | 22,752 lb (10,320 kg) | ↗ |
| Operating weight (min.-max.) | 23,424–26,136 lb (10,625–11,855 kg) | ↗ |
| Shipping weight | 22,752 lb (10,320 kg) | ↗ |
| Starter battery Voltage | 12 V | ↗ |
| Stroke | 4.3 in (110 mm) | ↗ |
| Travel speed | 30 km/h | ↗ |
| Travel speed (Option) | 40 km/h | ↗ |
| Width | 96.5 in (2,450 mm) | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
