Bobcat
T870
12,926 lb (5,863 kg)
Poids en service
Documents
Spécifications complètes
| Bucket Width | 84.8 in. (2154 mm) | ↗ |
| Cab Height | 83.6 in. (2123 mm) | ↗ |
| Diesel Exhaust Fluid (DEF) | 6.8 gal. (25.7 L) | ↗ |
| Diesel Particulate Filter (DPF) Requirement | No | ↗ |
| Engine | Tier 4 | ↗ |
| Fuel Tank Capacity | 32.6 gal. (123.4 L) | ↗ |
| Ground Pressure (with standard tracks) | 4.8 psi (.033 MPa) | ↗ |
| Height to Hinge Pin | 144.0 in. (3658 mm) | ↗ |
| Horsepower | 100 hp | ↗ |
| Hydraulic High Flow (optional) | 36.6 gpm (138.5 L/min.) | ↗ |
| Hydraulic Standard Flow | 23.0 gpm (87.1 L/min.) | ↗ |
| Hydraulic System Pressure | 3500 psi (24.13 MPa) | ↗ |
| Length of Track on Ground | 70.2 in (1783 mm) | ↗ |
| Lift Arm Path | Vertical | ↗ |
| Loader Series | M2-Series | ↗ |
| Operating Capacity (50% of tipping load) | 5,215 lb. (2365 kg) | ↗ |
| Operating Weight | 12,925 lb. (5863 kg) | ↗ |
| Rated Operating Capacity (ROC) | 3650 lb. (1656 kg) | ↗ |
| Tipping Load | 10,430 lb. (4731 kg) | ↗ |
| Track Width – Standard | 17.7 in. (450 mm) | ↗ |
| Travel Speed – High Range | 9.3 mph (15.0 km/hr.) | ↗ |
| Travel Speed – Single Speed | 5.5 mph (8.9 km/hr.) | ↗ |
| Type | Turbo Diesel | ↗ |
Chaque valeur est retracée jusqu’aux données publiées par le fabricant. ↗ ouvre la source.
