JLG
E300AJP
20.1 ft (6.1 m)
Max reach
15,399 lb (6,985 kg)
Operating weight
500 lb (227 kg)
Platform capacity
29.4 ft (9.0 m)
Working height
25%
gradeability
168 psi
ground pressure
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Max reach | Operating weight | Platform capacity |
|---|---|---|---|---|
| Haulotte HA12 CJ+ | 96% | 22.8 ft (6.9 m) | 15,675 lb (7,110 kg) | 507 lb (230 kg) |
| Dingli BA18NE | 95% | - | 17,042 lb (7,730 kg) | - |
| Dingli BA16NE | 90% | - | 14,771 lb (6,700 kg) | - |
| Snorkel A46JE | 90% | 24.9 ft (7.6 m) | 14,689 lb (6,663 kg) | 500 lb (227 kg) |
| XCMG XGA32ACJ-ANSI | 89% | - | - | 507 lb (230 kg) |
| Genie Z-30/20 N RJ Articulated Boom Lift | 89% | - | 14,220 lb (6,450 kg) | 500 lb (227 kg) |
Documents
Full specifications
| Gradeability | 25% | ↗ |
| Horizontal Outreach | 20 ft 1 in | ↗ |
| Machine Length | 18 ft (5.5 m) | ↗ |
| Machine Weight | 15,400 lb (6,985 kg) | ↗ |
| Machine Width | 4 ft (1.2 m) | ↗ |
| Max Platform Height | 29 ft 5 in | ↗ |
| Platform Capacity | 500 lb (227 kg) | ↗ |
| Platform Capacity Unrestricted | 500 lb (227 kg) | ↗ |
| Platform Height | 29 ft (8.8 m) | ↗ |
| Swing | 350 ° | ↗ |
| Turning Radius | 5 ft (1.5 m) | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
