JLG
RT2669
8,627 lb (3,913 kg)
Operating weight
1,499 lb (680 kg)
Platform capacity
26 ft (7.9 m)
Working height
5.6 km/h
drive speed lowered
40%
gradeability
50 L
hydraulic reservoir
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Operating weight | Platform capacity | Working height |
|---|---|---|---|---|
| MEC 3084RT Speed Level | 91% | - | 1,499 lb (680 kg) | 30 ft (9.1 m) |
| Snorkel S6926RTE | 91% | - | 1,499 lb (680 kg) | 32 ft (9.8 m) |
| Genie GS-2669-RT | 91% | 7,150 lb (3,243 kg) | - | 32.8 ft (10.0 m) |
| Snorkel SL26RT | 90% | 7,826 lb (3,550 kg) | 1,499 lb (680 kg) | - |
| Dingli JCPT2223RTB | 88% | - | 1,653 lb (750 kg) | 22 ft (6.7 m) |
| Dingli JCPT2223HRT | 88% | - | 1,653 lb (750 kg) | 22 ft (6.7 m) |
Documents
Full specifications
| Drive Speed (Raised) | 0.5 mph | ↗ |
| Gradeability | 40 | ↗ |
| Machine Height | 8 ft 0 in | ↗ |
| Machine Width | 69.3- in | ↗ |
| Max Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Max Platform Height | 26 ft 2 in | ↗ |
| Max Tilt Rating | 2.5 Degree | ↗ |
| Number of Occupants | 4 | ↗ |
| Platform Capacity | 1,500 lb (680 kg) | ↗ |
| Platform Extension Capacity | 300 lb (136 kg) | ↗ |
| Platform Height | 26- ft | ↗ |
| Turning Radius | 6 ft 11 in | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
