Sullair
DSP Series Oil Free Air Compressors
Documents
Full specifications
| DSP11009AV | - 150 hp (110 kW), 125 psi (8.6 bar), 611 cfm (17.3 m³/min) | ↗ |
| DSP11009AY | - 150 hp (110 kW), 125 psi (8.6 bar), 611 cfm (17.3 m³/min) | ↗ |
| DSP11009WV | -150 hp (110 kW), 125 psi (8.6 bar), 622 cfm (17.6 m³/min) | ↗ |
| DSP11009WY | - 150 hp (110 kW), 125 psig (8.6 bar), 622 cfm (17.6 m³/min) | ↗ |
| DSP13209WY | - 175 hp (132 kW), 125 psi (8.6 bar), 770 cfm (21.8 m³/min) | ↗ |
| DSP13210AY | - 175 hp (132 kW), 125 psi (8.6 bar), 742 cfm (21.0 m³/min) | ↗ |
| DSP14509WY | - 200 hp (145 kW), 125 psi (8.6 bar), 837 cfm (23.7 m³/min) | ↗ |
| DSP14510AY | - 200 hp (145 kW), 125 psi (8.6 bar), 805 cfm (22.8 m³/min) | ↗ |
| DSP16009WV | - 215 hp (160 kW), 125 psi (8.6 bar), 925 cfm (26.2 m³/min) | ↗ |
| DSP16009WY | - 215 hp (160 kW), 125 psi (8.6 bar), 925 cfm (26.2 m³/min) | ↗ |
| DSP16010AY | - 215 hp (160 kW), 125 psi (8.6 bar) 894 cfm (25.3 m³/min) | ↗ |
| DSP20009WY | - 250 hp (200 kW), 125 psi (8.6 bar), 1169 cfm (33.1 m³/min) | ↗ |
| DSP20010AY | - 250 hp (200 kW), 125 psi (8.6 bar), 1169 cfm (33.1 m³/min) | ↗ |
| DSP2209AY | - 30 hp (22 kW), 125 psi (8.6 bar), 117 cfm (3.3 m³/min) | ↗ |
| DSP24009WV | - 300 hp (240 kW), 125 psi (8.6 bar), 1303 cfm (36.9 m³/min) | ↗ |
| DSP24009WY | - 300 hp (240 kW), 125 psi (8.6 bar), 1303 cfm (36.9 m³/min) | ↗ |
| DSP24010AY | - 300 hp (240 kW), 125 psi (8.6 bar), 1296 cfm (36.7 m³/min) | ↗ |
| DSP3009AY | - 40 hp (30 kW), 125 psi (8.6 bar), 141 cfm (4.0 m³/min) | ↗ |
| DSP3709AV | - 50 hp (37 kW), 125 psi (8.6 bar), 162 cfm (4.6 m³/min) | ↗ |
| DSP3709AY | - 50 hp (37 kW), 125 psi (8.6 bar), 166 cfm (4.7 m³/min) | ↗ |
| DSP4509AY | - 60 hp (45 kW), 125 psi (8.6 bar), 230 cfm (6.5 m³/min) | ↗ |
| DSP4509WY | - 60 hp (45 kW), 125 psi (8.6 bar), 236 cfm (6.7 m³/min) | ↗ |
| DSP5509AY | - 75 hp (55 kW), 125 psi (8.6 bar), 272 cfm (7.7 m³/min) | ↗ |
| DSP5509WY | - 75 hp (55 kW), 125 psi (8.6 bar), 279 cfm (7.9 m³/min) | ↗ |
| DSP7509AY | - 100 hp (75 kW), 125 psi (8.6 bar), 385 cfm (10.9 m³/min) | ↗ |
| DSP7509WY | - 100 hp (75 kW), 125 psi (8.6 bar), 399 cfm (11.3 m³/min) | ↗ |
| DSP9009AV | - 125 hp (90 kW), 125 psi (8.6 bar), 544 cfm (15.4 m³/min) | ↗ |
| DSP9009AY | - 125 hp (90 kW), 125 psi (8.6 bar), 544 cfm (15.4 m³/min) | ↗ |
| DSP9009WV | - 125 hp (90 kW), 125 psi (8.6 bar), 551 cfm (15.6 m³/min) | ↗ |
| DSP9009WY | - 125 hp (90 kW), 125 psi (8.6 bar), 551 cfm (15.6 m³/min) | ↗ |
| Flow | 117 - 1303 cfm | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
