XCMG
XCA275_U
551,156 lb (250 t)
Lifting capacity
Documents
Full specifications
| Dead Weight in Travel State | 137024 lb kg | ↗ |
| Dimensions | 50.7x10.2x13.2 ft mm | ↗ |
| Drive engine model | OM471LA.E4-1 OM471LA.E5-1 | ↗ |
| Drive engine power | 523.0 bhp kw | ↗ |
| Drive/Steering | 10x8x10 | ↗ |
| Driving speed | 49.7 mph km/h | ↗ |
| Emission standard | EU Stage IV、EPA /CARB Tier 4 final EU Stage V、EPA /CARB Tier 4 final | ↗ |
| Max. hoist height | 354.3 ft m | ↗ |
| Max. load capacity | 275 Ust | ↗ |
| Max.load moment | 5009.1 kipf·ft kN.m | ↗ |
| Number of axles | 5 | ↗ |
| Telescopic boom | 239.5 ft m | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
