CAT CLASS: HQ-10450

1,200+ cfm Air Scrubber / Negative Air Machine

The 1,200+ cfm air scrubber / negative air machine is the high-capacity class designed for large containments and industrial work, delivering airflow from 1,650 to 4,000 cfm. These machines provide the air changes that previously required multiple mid-size units, streamlining labor-intensive setups on major abatement and remediation projects. This size represents the top rung of the air scrubber ladder, above the 600–1,200 cfm Air Scrubber / Negative Air Machine.

Modelos

Marcas

Cat classes

Elija una clase de tamaño — la capacidad y el alcance varían en la gama.

Especificaciones clave

Especificación	Rango típico	Qué significa
Airflow	1,650–4,000 cfm	Cubic feet per minute; determines containment volume and air-change rate capability
Filtration stages	3–4 stages (pre-filter, HEPA, optional carbon)	Sequential filtration captures progressively smaller particulate and odors
Motor configuration	Dual or variable-speed blowers	Multiple motors or variable drives allow precise pressure control in large spaces
Static pressure	Up to 4.0 in. w.g.	Inches of water gauge; ability to maintain negative pressure through ductwork and filters

Cómo elegir

This size class is appropriate when containment volume, air-change requirements, or static pressure demands exceed what the 600–1,200 cfm Air Scrubber / Negative Air Machine can sustain—typically on multi-story industrial abatement, large hospital wings, or remediation zones covering thousands of square feet. For smaller containments, mold jobs in residential or light-commercial settings, or projects where portability and reduced power draw are priorities, the 600–1,200 cfm Air Scrubber / Negative Air Machine is the better choice. When a single machine must serve an entire floor or maintain negative pressure through extensive duct runs, the 1,200+ cfm class consolidates equipment and simplifies monitoring.

Lo que maneja este tamaño

Asbestos abatement in multi-story hospital wings or manufacturing facilities
Remediation of warehouse fire or water damage spanning 10,000+ sq ft
Lead paint removal containments in large institutional buildings
Industrial mold remediation requiring multiple air changes per hour across several zones
Negative-pressure isolation during demolition of contaminated process areas
High-rise construction dust and particulate control on occupied floors

Seguridad y operación

HEPA filters must be sealed and tested to maintain containment integrity; bypass negates negative pressure
Pressure monitoring (manometers or alarms) required to verify continuous negative differential
Pre-filters require frequent inspection and changeout to prevent blower overload and airflow loss
Machines drawing high amperage should be locked out and tagged during filter service to prevent accidental startup

Transporte y logística

Machines typically weigh 150–300 lb and require pallet jack, appliance dolly, or two-person carry
Most units fit through standard doorways on carts; larger models may need freight elevator or exterior hoist for upper floors
Pickup truck bed or enclosed trailer sufficient; rigging and securing necessary for machines above 200 lb

Alimentación

208–240 V single-phase or three-phase circuits common; amperage ranges 10–20 A depending on motor configuration
Dual-motor units may require dedicated 20 A circuits or temporary distribution to avoid nuisance tripping
Generator compatibility requires clean sine-wave output and sufficient surge capacity for blower startup

Preguntas frecuentes

How many air changes per hour does a 1,200+ cfm machine provide?

Air changes depend on containment volume. A 2,000 cfm machine in a 10,000 cu ft space delivers 12 ACH; in a 20,000 cu ft zone, 6 ACH. Regulatory minimums vary by jurisdiction and contaminant type.

Can one high-capacity unit replace multiple smaller machines?

Often, yes—provided ductwork distributes airflow evenly and static pressure remains within spec. Multiple smaller units offer redundancy and zoned control; a single large machine simplifies monitoring but represents a single point of failure.

What filtration efficiency is standard at this size?

HEPA filters rated 99.97% at 0.3 microns are standard. Some models add activated carbon stages for VOC and odor control; others offer ULPA (99.999%) filtration for pharmaceutical or semiconductor work.
