8,000-12,000 lb Cushion Tire Forklift
The 8,000-12,000 lb cushion tire forklift is a heavy-duty size class designed for machinery crates, banded steel, and consolidated loads that exceed the capability of lighter equipment. With rated capacities between 3,629 and 5,443 kg (approximately 8,000-12,000 lb), these forklifts bridge the gap between standard warehouse equipment and the largest industrial machines. This size sits fourth on the cushion tire forklift ladder, above the 6,000-8,000 lb class and below the 12,000+ lb category.
Cat classes
Pick a size class — capacity and reach differ across the range.
Key specifications
| Specification | Typical range | What it means |
|---|---|---|
| Load capacity | 8,000–12,000 lb (3,629–5,443 kg) | Maximum load the forklift can safely lift at rated load center |
| Lift height | 4.7–19.8 ft (1.4–6.0 m) | Maximum fork elevation, varies widely by mast configuration |
| Tire type | Cushion (solid rubber) | Non-pneumatic tires optimized for smooth concrete and asphalt surfaces |
| Chassis design | Compact wheelbase | Shorter turning radius than pneumatic models for indoor and tight outdoor spaces |
How to choose
This size class is appropriate for operations handling machinery shipments, consolidated pallets of building materials, or industrial loads in the 4-5 ton range that routinely exceed 8,000 lb. The 6,000-8,000 lb Cushion Tire Forklift is sufficient for most mixed warehouse work and standard pallet loads, while the 12,000+ lb Cushion Tire Forklift becomes necessary when loads consistently approach or exceed six tons, such as steel coils, heavy fabrications, or equipment that arrives on reinforced crating. Operators should verify actual load weights and account for load center distance; a 10,000 lb forklift rated at 24-inch load center may be unable to safely lift a 9,000 lb crate if the center of gravity sits 36 inches forward.
What this size handles
- Unloading CNC machines and industrial equipment from flatbed trailers
- Moving banded steel plate and structural steel bundles in fabrication yards
- Handling multi-pallet loads consolidated on reinforced skids
- Warehouse operations with mezzanine racking requiring extended lift heights
- Loading and staging heavy crates for manufacturing assembly lines
- Moving large HVAC units and mechanical equipment on smooth concrete pads
Safety & operation
- Operator certification required under OSHA 1910.178 for powered industrial truck operation
- Load capacity decreases significantly as load center moves forward or lift height increases; consult load chart on each machine
- Cushion tires provide minimal shock absorption and limited traction on uneven or unpaved surfaces
- Rear-end swing radius requires clearance during turns; counterweight extends behind rear axle
Transport & logistics
- Typically requires flatbed or tilt-deck trailer rated for 15,000-20,000 lb total weight
- Most units fit within standard 8.5 ft trailer width; height with mast lowered generally under 8 ft
- Loading via drive-on ramps or dock; some machines exceed weight limits for standard equipment trailers
Power & supply
- Available in electric (battery), LP gas (propane), diesel, and dual-fuel configurations
- Electric models require 36V or 48V industrial battery charging stations with appropriate amperage
- Internal combustion models operate on standard LP cylinders (33 lb or larger) or diesel fuel tanks
Frequently asked
What distinguishes this size from the 6,000-8,000 lb class?
Can these forklifts operate outdoors?
How does lift height affect capacity in this size class?
Compare popular models
Find by spec →Normalised to the same units. A dash means the figure was not published.
| Model | Load capacity | Lift height | Engine power |
|---|---|---|---|
| Crown CB40 | 8,999 lb (4,082 kg) | 19.8 ft (6.0 m) | - |
| Hyster LO80 | 8,001 lb (3,629 kg) | 4.7 ft (1.4 m) | - |
| Nissan MXL40-MXL55H | 10,501 lb (4,763 kg) | 10.8 ft (3.3 m) | - |
| Unicarriers MXL40-MXL55H | 10,501 lb (4,763 kg) | 10.8 ft (3.3 m) | - |
Related equipment
Browse by manufacturer
Sources
Every specification is verified against the manufacturer's published data, with the source linked for reference.
8,000-12,000 lb Cushion Tire Forklift
20 models · Every spec cited to source
