27-34 ft Electric Scissor Lift
The 27-34 ft electric scissor lift class delivers platform heights from 27 to 34 feet, typically referenced as the 32 ft class in the rental industry. This size bridges mid-height indoor work and high-bay warehouse applications, providing the reach needed for warehouse racking, sprinkler main installation, and structural steel work inside buildings where outdoor rough-terrain models cannot operate.
Cat classes
Pick a size class — capacity and reach differ across the range.
Key specifications
| Specification | Typical range | What it means |
|---|---|---|
| Platform height | 27–32 ft (8.2–9.8 m) | Working height reaches 33–38 ft, accounting for operator reach above the platform. |
| Platform capacity | 500–700 lbs (227–318 kg) | Accommodates two operators plus tools and materials for elevated installation work. |
| Width | 32–46 in (81.3–117 cm) | Fits through standard double-door openings and navigates warehouse aisles while stowed. |
| Gradeability | 25–30% | Handles moderate floor slopes common in industrial facilities and loading areas. |
| Drive speed (elevated) | 0.5–0.7 mph | Allows repositioning at height within the same work zone without lowering the platform. |
How to choose
The 27-34 ft class is specified when platform height requirements exceed 26 feet but remain below 34 feet—typical for high-bay warehouse maintenance, upper-level racking, and roof structure access from inside the building. When work stays consistently below 26 feet, the 20-27 ft Electric Scissor Lift offers easier maneuverability in tighter spaces and lower transport height. For platform heights above 34 feet or outdoor structural work, the 34+ ft Electric Scissor Lift or rough-terrain models provide the necessary reach and stability.
What this size handles
- Installing or servicing warehouse racking systems at 28–32 ft storage levels
- Running sprinkler mains and fire suppression piping in high-bay facilities
- Mounting lighting fixtures and electrical conduit in distribution centers
- Accessing roof steel and purlin connections from inside the building envelope
- HVAC duct installation in tall retail or industrial interiors
- Signage and wayfinding installation in convention centers and airports
Safety & operation
- Pothole protection and tilt sensors prevent operation on uneven surfaces or excessive slopes
- Guardrails and mid-rails surrounding the platform meet ANSI A92 and CSA B354 fall-protection standards
- Descent alarm and platform overload indicators alert operators to unsafe conditions
- Outriggers or automatic leveling systems stabilize the base on sloped warehouse floors
Transport & logistics
- Typical operating weight of 6,000–8,500 lbs requires tandem-axle equipment trailer rated for 10,000+ lbs
- Stowed height of 8–9 ft allows transport under most bridge and overhead clearances without permits
- Width under 4 ft permits loading two units side-by-side on wider trailers
Power & supply
- Equipped with 24V, 36V, or 48V DC battery packs charged via standard 110V or 220V outlets overnight
- Battery runtime typically supports 6–8 hours of intermittent use per charge cycle
- Zero emissions make this class suitable for enclosed warehouse and climate-controlled environments
Frequently asked
What distinguishes the 27-34 ft class from smaller electric scissor lifts?
Can this size class operate on polished concrete warehouse floors?
What ceiling height is required to fully elevate a 27-34 ft scissor lift?
Compare popular models
Find by spec →Normalised to the same units. A dash means the figure was not published.
| Model | Working height | Platform capacity |
|---|---|---|
| Haulotte Compact 10N DUAL | 33.1 ft (10.1 m) | 551 lb (250 kg) |
| JLG ES3246 | 32 ft (9.8 m) | 705 lb (320 kg) |
| Haulotte Compact 12 DX | 39.9 ft (12.2 m) | 992 lb (450 kg) |
| MEC 3232SE | 38.1 ft (11.6 m) | 549 lb (249 kg) |
| Snorkel S4732E | 38 ft (11.6 m) | 769 lb (349 kg) |
| Genie GS-3246 E-Drive Scissor Lift | 38.5 ft (11.7 m) | 701 lb (318 kg) |
Related equipment
Browse by manufacturer
Sources
Every specification is verified against the manufacturer's published data, with the source linked for reference.
27-34 ft Electric Scissor Lift
53 models · Page 2 of 2 · Every spec cited to source
