Up to 20 ft Electric Scissor Lift
Electric scissor lifts up to 20 ft platform height—typically 19 ft—are the smallest and most compact units in the electric scissor category, designed for finished interior environments. With non-marking tires, narrow widths down to 30 inches, and working heights to 25 ft, these machines navigate standard doorways, freight elevators, and tight spaces where flooring and walls are already in place. They form the foundation rung of the electric scissor ladder, below the 20-27 ft Electric Scissor Lift class used for taller interior tasks.
Cat classes
Pick a size class — capacity and reach differ across the range.
Key specifications
| Specification | Typical range | What it means |
|---|---|---|
| Platform height | 3.7–19.0 ft (1.1–5.8 m) | Provides working height to approximately 25 ft for standard ceiling access |
| Platform capacity | 227–500 kg (500–1,102 lb) | Supports one or two operators with tools and materials |
| Overall width | 0.8–76.2 ft (0.2–23.2 m) | Narrow models pass through standard doorways and residential hallways |
| Operating weight | 759.8–3,164.0 kg (1,675–6,976 lb) | Range accommodates compact models suitable for upper-floor slabs and elevator transport |
How to choose
This size class is appropriate when work occurs in finished interiors with restricted access and standard ceiling heights. The 19 ft platform height suits tasks in commercial buildings with 12–20 ft ceilings, and the narrow frame navigates doorways, corridors, and freight elevators without modification. When platform heights above 20 ft are required—such as high-bay retail spaces, atriums, or multi-story warehouses—the 20-27 ft Electric Scissor Lift becomes necessary. Outdoor applications or rough terrain generally require engine-powered rough-terrain scissor lifts instead.
What this size handles
- Installing recessed lighting and electrical fixtures in office ceilings
- Running HVAC ductwork and sprinkler pipe in retail fit-outs
- Hanging and finishing drywall in commercial interiors
- Painting and trim work in hotel lobbies and corridors
- Inspecting and servicing ceiling-mounted equipment in hospitals
- Setting ceiling tile grids in schools and municipal buildings
Safety & operation
- Non-marking tires protect finished flooring; ensure floor loading capacity meets or exceeds machine operating weight plus dynamic loads
- Fall protection harnesses and guardrails are standard; operators must secure lanyards to designated anchor points per ANSI A92.20 standards
- Pothole and drop-off protection required; lifts must operate on level surfaces within manufacturer gradeability limits (typically 25–30%)
- Maintain clearance from overhead obstructions, electrical wiring, and structural elements throughout the lift's range of motion
Transport & logistics
- Most units fit in standard enclosed trailers or on lightweight flatbed trailers; operating weights from 760 kg to 3,164 kg span compact models suitable for half-ton truck towing to heavier configurations
- Compact width and weight of smaller models permit loading into freight elevators rated for 3,000+ lb, enabling multi-story interior access without crane lifts
- Some models fold or retract for transport in box trucks or cargo vans
Power & supply
- Electric battery power (typically 24V or 48V DC); units recharge from standard 110V or 220V AC outlets overnight or between shifts
- Run-time varies with duty cycle but generally supports a full work shift; zero emissions and low noise suit occupied buildings
- No on-site fuel storage or ventilation requirements
Frequently asked
What is the maximum working height for this size class?
Will a 19 ft electric scissor fit through a standard doorway?
What differentiates this class from taller electric scissor lifts?
Compare popular models
Find by spec →Normalised to the same units. A dash means the figure was not published.
| Model | Working height | Platform capacity |
|---|---|---|
| JLG ES1932 | 19 ft (5.8 m) | 507 lb (230 kg) |
| Custom Equipment PS-1030 | 16 ft (4.9 m) | 800 lb (363 kg) |
| Custom Equipment PS-1430 | 20 ft (6.1 m) | 701 lb (318 kg) |
| Custom Equipment ZT-1230 | 18 ft (5.5 m) | 650 lb (295 kg) |
| Genie GS-1930 | 25.6 ft (7.8 m) | 1,102 lb (500 kg) |
| Genie GS-1932 | 25.6 ft (7.8 m) | 1,102 lb (500 kg) |
