14,000-26,000 lb Equipment Trailer
The 14,000-26,000 lb equipment trailer class represents the heaviest non-CDL hauling tier, built on tandem and tri-axle configurations for demanding commercial work. This size band bridges medium-duty construction and the threshold where federal commercial driving regulations begin. It sits above the 10,000-14,000 lb class and below the 26,000+ lb CDL-required category.
Cat classes
Pick a size class: capacity and reach differ across the range.
Key specifications
| Specification | Typical range | What it means |
|---|---|---|
| Load capacity | 6,400-11,700 kg (14,000-26,000 lb) | Defines maximum payload; heaviest non-CDL tier in the equipment trailer ladder |
| Axle configuration | Tandem or tri-axle | Multiple axles distribute weight across roadway and improve stability under heavy loads |
| GVWR | Approaches 26,000 lb threshold | Gross vehicle weight rating stays below the federal CDL requirement |
| Deck length | 18–24 ft (5.5–7.3 m) | Accommodates excavators, skid steers, and compact dozers typical of commercial sites |
How to choose
This size class is appropriate when hauling excavators, skid steers, compact track loaders, or utility vehicles that exceed the 10,000-14,000 lb Equipment Trailer capacity but work must remain within non-CDL limits. Contractors choose this tier to maximize payload without triggering commercial driver licensing, medical certification, or hours-of-service logs. When combined trailer and load exceed 26,000 lb GVWR, the 26,000+ lb Equipment Trailer class is required along with a CDL-licensed operator. Conversely, jobs consistently under 14,000 lb GVWR gain maneuverability and lower tow-vehicle demands with the 10,000-14,000 lb Equipment Trailer class.
What this size handles
- Hauling 8,000-10,000 lb compact excavators to residential or light commercial sites
- Transporting multiple skid steers or a single compact track loader for earthmoving
- Moving utility tractors, ride-on rollers, or trenchers for municipal maintenance crews
- Delivering concrete buggies, plate compactors, and walk-behind equipment in tandem
- Shuttling generators, light towers, and welders for job-site power staging
- Hauling landscape equipment including mini skid steers and turf rollers for park projects
Safety & operation
- GVWR must remain below 26,000 lb to avoid CDL requirements; operators verify combined trailer, payload, and fuel weights before each haul
- Tri-axle configurations improve weight distribution and braking but increase turning radius and curb sensitivity
- Load securement per FMCSA regulations: chains, straps, or binders rated to working load limit; four tie-down points minimum for most equipment
- Tandem and tri-axle trailers require wider clearance at gates, intersections, and on narrow job-site roads
Transport & logistics
- Requires heavy-duty pickup truck (3/4-ton minimum, often 1-ton dually) or medium-duty commercial chassis rated for 14,000-26,000 lb towing
- Trailer brakes (electric or surge) and brake controller mandatory; many jurisdictions require breakaway systems and safety chains rated to GVWR
- Loading via drive-on ramps (fold-down or removable) or stand-up ramps with equipment under its own power; deck height typically 18-24 inches
Power & supply
- Equipment trailers in this class are unpowered; hauled machinery may carry onboard diesel, gasoline, or electric power systems
- Some models include battery boxes or tool storage; no integral generator or hydraulic power unit
