CAT CLASS: HQ-10194

100,000+ lb Track Excavator

The 100,000+ lb track excavator class represents the largest production machines in the excavator family, starting at 50 tons and ranging up to 200 tons operating weight. These machines are engineered for quarry operations, mining applications, and large-scale civil earthwork where production volume and cycle efficiency justify their scale. This is the top rung of the track excavator ladder, with no larger size class above it.

544

Modelos

Marcas

Cat classes

Elija una clase de tamaño — la capacidad y el alcance varían en la gama.

Especificaciones clave

Especificación	Rango típico	Qué significa
Operating weight	47,500–400,976 kg (104,700–884,000 lb)	Defines the machine's stability, breakout force, and the infrastructure required to transport and support it on site.
Engine power	25.5–1999.5 hp	Diesel engines scaled to move bucket loads measured in cubic yards; higher-end models approach 2,000 hp for mining-duty cycles.
Max dig depth	12.2–52.4 ft (3.7–16.0 m)	Vertical reach below grade; largest models exceed 50 feet for deep quarry benching and minepit development.
Max reach	35–11,800 ft (10.7–3,597 m)	Horizontal working envelope from the machine centerline; extended-reach configurations serve dredging and mass excavation.

Cómo elegir

This size class is appropriate when production volume, dig depth, or reach exceed the capacity of smaller excavators, or when the work involves high-density material that demands maximum breakout force. Quarry shot rock loading, mine overburden removal, large dam construction, and deep foundation excavation all justify machines in this weight range. For large earthwork that does not require extreme dig depth or bucket capacity—highway cuts, site grading, utility corridor work—the 70,000-100,000 lb Track Excavator class often provides better mobility and lower transport costs. There is no step up from this class; projects requiring still greater production typically deploy multiple units or purpose-built mining shovels.

Lo que maneja este tamaño

Loading 100-ton haul trucks in aggregate quarries and open-pit mines
Mass excavation for dam construction and reservoir development
Deep foundation and caisson work where dig depth exceeds 40 feet
Overburden stripping in surface coal and mineral mining operations
Large-scale land reclamation and port dredging with long-reach configurations
Rock face scaling and bench production in dimensional stone quarries

Seguridad y operación

Operator certification for machines over 50 tons is often required by site safety plans and insurance underwriters
Ground bearing pressure and compaction must be evaluated; reinforced haul roads and working pads are standard on soft or engineered fill
Proximity detection systems, cameras, and grade-control integration are common on larger models to manage blind spots and prevent contact with personnel or equipment
Swing radius and counterweight clearance require exclusion zones; spotter coordination is typical in congested quarry or construction environments

Transporte y logística

Requires multi-axle lowboy or RGN trailers rated for 50–200+ tons; most moves exceed legal width and weight limits
Oversize/overweight permits and specialized heavy-haul carriers coordinate routing and escort requirements
Machines are often transported with boom and arm removed; field reassembly by factory-trained technicians is standard

Alimentación

Diesel fuel consumption ranges from 15 to over 100 gallons per hour depending on model and duty cycle; on-site bulk fuel storage is typical
High-horsepower models may require diesel particulate filters (DPF) and selective catalytic reduction (SCR) systems with diesel exhaust fluid (DEF) supply

Preguntas frecuentes

What differentiates a 100,000+ lb excavator from smaller classes in production capability?

Bucket capacity, breakout force, and cycle time scale with weight class. Machines in this range handle 4–15+ cubic yard buckets and can load 100-ton haul trucks in 3–5 passes, a production rate unattainable with lighter excavators.

Why does max reach vary so widely in this class?

Standard configurations prioritize dig depth and bucket capacity, yielding reach around 35–50 feet. Extended-reach and ultra-high-reach (UHR) variants sacrifice bucket size for horizontal reach exceeding 150 feet, used in dredging, river work, and slope stabilization.

How does operating weight affect site access and ground conditions?

Machines over 200,000 lb exert ground pressure that can exceed the bearing capacity of unimproved soil or thin pavement. Engineered access roads, compacted aggregate working pads, and geotechnical analysis are standard practice for the heaviest models in this class.

Comparar modelos populares

Buscar por especificación →

Normalizado a las mismas unidades. Un guion significa que el valor no fue publicado.

Modelo	Peso operativo	Profundidad de excavación máx	Alcance máx	Potencia del motor
Case CX490C	105,381 lb (47,800 kg)	-	38.7 ft (11.8 m)	362 hp
Komatsu PC1250-8	234,792 lb (106,500 kg)	-	-	673 hp
Hitachi EX2000-7	429,901 lb (195,000 kg)	14.4 ft (4.4 m)	44.3 ft (13.5 m)	746 hp
Hitachi EX3600-7	815,710 lb (370,000 kg)	14.4 ft (4.4 m)	51.5 ft (15.7 m)	1,450 hp
Hitachi ZX490LCH-7	113,097 lb (51,300 kg)	22.1 ft (6.7 m)	36.8 ft (11.2 m)	397 hp
Hitachi ZX530LCH-7	118,609 lb (53,800 kg)	22 ft (6.7 m)	36.5 ft (11.1 m)	397 hp
