130-200 hp Dozer

The 130–200 hp dozer represents the D6 class, the mass-grading workhorse of the dozer family. This size class handles road subgrade preparation, pond construction, and long push work where productivity and fuel efficiency balance across extended runs. Positioned between the 90–130 hp and 200–300 hp bands, this class delivers the power density most земляных работ general earthwork contractors rely on daily.

98
Models
10
Brands
Dozer

Cat classes

Pick a size class — capacity and reach differ across the range.

All sizes
98 models
Up to 90 hp
Up to 90 hp
3 models
90-130 hp
90-130 hp
6 models
130-200 hp
130-200 hp
10 models
200-300 hp
200-300 hp
10 models
300+ hp
300+ hp
8 models
Other sizes
Other sizes
61 models

Key specifications

SpecificationTypical rangeWhat it means
Engine power103–185 hpMid-range output for sustained pushing and grading without the fuel penalty of larger machines
Operating weight29,101–53,462 lb (13,200–24,250 kg)Mass sufficient for traction on moderate grades and cohesive soils without excessive ground pressure
Blade capacity2.5–4.0 m³Balanced for 30–60 m push distances common in site prep and road construction
Drawbar pull110–150 kNAdequate for ripping weathered rock and pushing loaded scrapers in tandem operations

How to choose

The 130–200 hp band suits mass grading on sites requiring 1,000+ m³/day moved over moderate push distances, road subgrade stripping, and pond or basin excavation where long, sustained pushes justify the operating cost. Step down to the 90–130 hp Dozer for finish grading, residential subdivision work, or confined sites where maneuverability outweighs raw production; that class also reduces transport and fuel expense on smaller projects. Step up to the 200–300 hp Dozer when push distances exceed 80 m, when ripping hard rock or caliche, or when moving 3,000+ m³/day on large highway or dam projects where the production gain offsets the higher hourly cost.

What this size handles
  • Highway subgrade stripping and rough grading across 5–10 km corridor sections
  • Detention pond and stormwater basin excavation with 50–80 m push to spoil
  • Landfill cell construction and daily cover spreading
  • Commercial pad site prep moving 1,500–2,500 m³/day
  • Agricultural land leveling and reservoir dam construction
  • Pipeline right-of-way clearing and backfill spreading in open terrain

Safety & operation
  • ROPS/FOPS certified cab standard; falling-object protection critical in land-clearing and demolition applications
  • Blade and ripper create significant crush and shear zones; 10 m exclusion perimeter during operation
  • Ground-level fueling and service points reduce fall risk; lockout/tagout procedures required for track and undercarriage work
  • Slope operation limits typically 35–45% side slope, 55–65% climbing grade; stability varies with track configuration and soil conditions

Transport & logistics
  • Requires tandem-axle tag trailer or 3-axle lowboy rated 25–30 tonnes; exceeds single-axle trailer capacity
  • Transport width typically 2.4–3.0 m with standard blade; some configurations require pilot car or width permits
  • Loading via integrated hydraulic tilt blade and reversing onto trailer deck; 4.0–4.5 m deck height clearance needed

Power & supply
  • Diesel fuel consumption 15–25 L/hr under typical load; 200–300 L on-board capacity supports 10–14 hr runtime
  • Turbocharged diesel engines meeting Tier 4 Final or Stage V emissions standards in current models
  • Daily DEF (diesel exhaust fluid) replenishment required on emissions-compliant units; 10–20 L tank capacity

Frequently asked
What differentiates a 130–200 hp dozer from a 200–300 hp model in production?
The 130–200 hp class optimizes fuel economy and maneuverability for push distances under 80 m and daily volumes under 3,000 m³, while the 200–300 hp band delivers 30–50% higher production on long pushes and hard materials at the cost of increased fuel burn and transport weight.
Can this size class handle rock ripping, or is a larger dozer required?
Most models in the 130–200 hp range accommodate single- or multi-shank rippers effective in weathered rock, soft limestone, and fractured shale; solid rock, cemented caliche, or deep ripping beyond 600 mm typically requires the drawbar pull and mass of the 200–300 hp class.
How does operating weight affect performance in wet or sandy conditions?
Machines at the upper end of the 20,000–24,000 kg range provide better traction and floatation with wide-gauge tracks, while lighter 13,000–16,000 kg models offer lower ground pressure with LGP (low ground pressure) undercarriage options; track selection often matters more than absolute weight.

Compare popular models

Find by spec →

Normalised to the same units. A dash means the figure was not published.

ModelOperating weightMax dig depthMax reachEngine power
John Deere 850P 29,064 lb (13,183 kg)58.7 ft (17.9 m)-145 hp
Case 1150M 31,134 lb (14,122 kg)--138 hp
Case 1650L 38,257 lb (17,353 kg)--164 hp
Caterpillar D6 48,788 lb (22,130 kg)--161 hp
Develon DD130 XL 31,074 lb (14,095 kg)--146 hp
Develon DD130 LGP 32,038 lb (14,532 kg)--146 hp
