CAT CLASS: HQ-10636

34+ ft Electric Scissor Lift

The 34+ ft electric scissor lift is the tallest size class in the slab-scissor category, delivering working heights from 40 to 47 feet for high-ceiling environments. These machines handle arena maintenance, distribution-center installations, and atrium work where vertical reach takes priority over terrain capability. This is the top rung of the electric scissor ladder; work below 40 feet typically moves to the 27–34 ft class.

511

Models

Brands

Cat classes

Pick a size class — capacity and reach differ across the range.

Key specifications

Specification	Typical range	What it means
Working height	40–47 ft (12.2–14.3 m)	Platform heights of 38–41 ft with guardrail clearance; the maximum reach available in electric slab scissors.
Platform capacity	500–750 lb (227–340 kg)	Smaller deck capacities than mid-size units, reflecting the structural limits of tall scissor stacks.
Operating weight	12,000–16,850 lb (5,443–7,643 kg)	Heavy base counterweight required for stability at full extension; impacts transport and floor loading.
Drive speed (stowed)	3.0–4.8 mph	Slow travel speed reflects the tall, narrow profile and need for precise positioning indoors.
Gradeability	23–45%	Rated for level slabs and gentle ramps only; not designed for outdoor grades or uneven surfaces.

How to choose

This size class is justified when the work envelope exceeds 40 feet and the site offers flat, hard surfaces — large retail boxes, sports venues, convention halls, and cold-storage facilities with tall ceilings. When working heights fall between 34 and 40 feet, the 27–34 ft Electric Scissor Lift offers faster travel, higher deck capacity, and lighter transport weight. Outdoor high-reach work or uneven surfaces require rough-terrain scissors or boom lifts, not this category.

What this size handles

Installing or servicing lighting grids in professional sports arenas and concert venues
Warehouse racking installation and maintenance in distribution centers with 35+ ft clear heights
Façade and skylight access in multi-story hotel atriums and convention-center lobbies
HVAC ductwork and piping in manufacturing plants with tall production bays
Ceiling panel and fire-suppression work in big-box retail stores with mezzanines
Banner and display rigging for trade shows and exhibitions in large exhibition halls

Safety & operation

Tall scissor stacks amplify sway and instability; operators must avoid lateral forces, sudden stops, and driving with the platform raised above manufacturer limits.
Floor loading can exceed 100 lb/ft² at outrigger points; structural engineers should verify slab capacity, especially on elevated decks or older construction.
Overhead clearance planning is critical — full extension approaches 47 ft, and contact with roof structure or utilities can tip the machine or cause electrical hazards.
Fall protection, guardrail integrity, and gate latches must be inspected before every shift; the working height puts occupants at severe-injury risk in the event of a fall.

Transport & logistics

Operating weights of 12,000–16,850 lb require tandem-axle trailers rated for 14,000+ lb; many models exceed single-axle limits.
Overall widths of 4–6 ft and stowed heights near 10 ft allow passage through standard double doors, but turning radius and aisle width must be verified for interior access.
Long-distance moves often use lowboy or tilt-deck trailers; loading requires ramps rated for the unit's weight and wheelbase.

Power & supply

Battery-electric drive with 48V or 72V battery packs; larger models use deep-cycle lead-acid or AGM banks requiring 8–12 hour charge cycles.
On-site charging needs 208–240V single-phase or three-phase outlets; many facilities designate overnight charging areas to avoid disrupting workflow.
Runtime varies with duty cycle and temperature; cold environments and frequent raise/lower cycles reduce operating hours per charge.

Frequently asked

What separates this size from the 27–34 ft class?

Working heights above 40 feet. The 27–34 ft class tops out around 39–40 ft; the 34+ ft category begins at 40 ft and extends to 47 ft, addressing ceilings and structures the smaller size cannot reach.

Why is platform capacity lower than smaller scissor lifts?

Taller scissor stacks impose greater structural loads, so manufacturers reduce deck capacity to maintain stability and meet tipping-moment limits. Most 34+ ft models carry 500–750 lb versus 1,000+ lb on compact units.

Can these machines operate on sloped floors?

Only on minimal grades. Gradeability ratings of 23–45% apply to stowed travel on smooth ramps; operating the platform at height requires a level surface within the manufacturer's tilt-sensor tolerance, typically 0.5–1°.

Compare popular models

Find by spec →

Normalised to the same units. A dash means the figure was not published.

Model	Working height	Platform capacity
Haulotte C14	45.4 ft (13.8 m)	705 lb (320 kg)
Haulotte HS18 E MAX	59.1 ft (18.0 m)	1,653 lb (750 kg)
Snorkel S4740E	45.9 ft (14.0 m)	549 lb (249 kg)
Skyjack SJ-1256	-	-
Skyjack SJ-1256THS	-	-
Skyjack SJ7135	41.7 ft (12.7 m)	-
