JLG
1500SJ
74 hp
Engine power
82.1 ft (25.0 m)
Max reach
48,502 lb (22,000 kg)
Operating weight
150 ft (45.7 m)
Working height
4.8 km/h
drive speed
117 L
fuel tank capacity
Equivalent across brands
Compare side by side →Comparable machines from other manufacturers, scored on normalised, manufacturer-sourced specs.
| Model | Match | Engine power | Max reach | Operating weight |
|---|---|---|---|---|
| Haulotte HT43 RTJ PRO | 98% | 74 hp | - | 47,179 lb (21,400 kg) |
| Haulotte HT28 RTJ O | 93% | 74 hp | - | 39,463 lb (17,900 kg) |
| Haulotte HT28 RTJ PRO | 93% | 74 hp | 78.2 ft (23.8 m) | 39,904 lb (18,100 kg) |
| Genie S-125 | 92% | 78 hp | 81 ft (24.7 m) | 44,639 lb (20,248 kg) |
| Snorkel TB126J | 91% | 65 hp | - | 41,800 lb (18,960 kg) |
| Genie S-85 XC | 90% | 74 hp | 74.5 ft (22.7 m) | 39,500 lb (17,917 kg) |
Documents
Full specifications
| Axle Oscillation | 12 in (30.5 cm) | ↗ |
| Gradeability | 40% | ↗ |
| Horizontal Outreach | 80 ft 0 in | ↗ |
| Max Platform Capacity | 1,000 lb (454 kg) | ↗ |
| Max Platform Height | 150 ft 0 in | ↗ |
| Swing | 360 ° | ↗ |
Every figure is traced to the manufacturer’s published data. ↗ opens the source.
