26-36 ft Self-Propelled Mast Lift
The 26-36 ft self-propelled mast lift serves retail and warehouse maintenance, high-bay lighting installations, and interior jobs requiring a compact footprint that navigates standard aisles. This size class bridges compact indoor units and larger exterior-capable machines, offering working heights from 26 to approximately 36 feet. With platform capacities typically 136–350 kg and widths around 0.8 m, these machines prioritize vertical reach in confined spaces.
Cat classes
Pick a size class — capacity and reach differ across the range.
Key specifications
| Specification | Typical range | What it means |
|---|---|---|
| Working height | 26–36 ft (7.9–11.0 m) | Defines the class; suits high-bay lighting, retail ceiling work, and warehouse racking access. |
| Platform capacity | 300–772 lb (136–350 kg) | Accommodates operator plus tools and materials for typical maintenance tasks. |
| Width | 0.8 m (31.5 in) | Narrow chassis fits through standard doorways and between warehouse racking. |
| Operating weight | 2,072–5,842 lb (940–2,650 kg) | Heavier models offer greater stability; lighter units simplify transport and indoor floor loading. |
| Drive speed | 4.5–5.5 km/h | Modest travel speed suited to controlled indoor environments and short repositioning. |
How to choose
The 26-36 ft class is appropriate for retail ceiling maintenance, warehouse lighting retrofits, and interior construction at heights beyond scissor-lift reach but not requiring boom articulation. Tasks confined to hard, level floors in climate-controlled buildings fit this band. When working heights remain below 26 feet and loads are heavier, the Up to 26 ft Self-Propelled Mast Lift offers greater platform capacity and lower cost. For working heights exceeding 36 feet, outdoor sites, or applications needing horizontal outreach, the 36+ ft Self-Propelled Mast Lift or a boom lift becomes necessary.
What this size handles
- Replacing high-bay LED fixtures in a warehouse with 30-ft ceilings and narrow aisles
- Installing signage and displays in retail spaces with 28-ft ceiling clearance
- Servicing HVAC diffusers and ductwork in distribution centers
- Painting or repairing ceilings in large-format retail stores
- Running electrical conduit or data cables in manufacturing facilities with limited floor space
- Inspecting or maintaining overhead conveyor systems in tight production areas
Safety & operation
- Vertical mast design limits horizontal reach, reducing tip-over risk compared to boom lifts but requiring positioning directly beneath the work
- Narrow footprint and elevated center of gravity require firm, level surfaces; uneven floors or slopes beyond 23–30% gradeability exceed safe operating limits
- Outriggers or stabilizers are typically absent; machine stability depends on chassis weight distribution and surface condition
- Overhead clearance during transit and setup must account for stowed height, often 2–2.5 m, to avoid collisions with sprinkler heads, ductwork, or doorframes
Transport & logistics
- Operating weights of 940–2,650 kg allow transport on single-axle or tandem-axle utility trailers rated 1,500–3,500 kg
- Compact 0.8 m width permits loading through standard overhead doors and movement in service elevators where height permits
- Lighter models within the class may be moved by half-ton pickup trucks; heavier units require 3/4-ton or larger tow vehicles
Power & supply
- Electric-powered models dominate this class, drawing from onboard battery packs recharged via standard 110V or 220V outlets
- Typical runtime of 4–8 hours per charge suits a full shift of intermittent positioning and elevation
- Indoor operation eliminates exhaust emissions and reduces noise compared to engine-driven alternatives
Frequently asked
What differentiates a 26-36 ft mast lift from a scissor lift at the same height?
Can this size class operate on sloped or uneven warehouse floors?
How does platform capacity vary within the 26-36 ft class?
Compare popular models
Find by spec →Normalised to the same units. A dash means the figure was not published.
| Model | Working height | Platform capacity |
|---|---|---|
| Dingli AMWP9.5-1200 | 31.2 ft (9.5 m) | 300 lb (136 kg) |
| JLG 25AM | 31 ft (9.4 m) | 351 lb (159 kg) |
| Dingli AMWP8-1200 | 26.2 ft (8.0 m) | 351 lb (159 kg) |
| Genie GR-20 | 26.5 ft (8.1 m) | 351 lb (159 kg) |
| Haulotte Quick Up 11 | 35.4 ft (10.8 m) | 351 lb (159 kg) |
| JLG 30AM | 35.7 ft (10.9 m) | 351 lb (159 kg) |
Related equipment
Browse by manufacturer
Sources
Every specification is verified against the manufacturer's published data, with the source linked for reference.
26-36 ft Self-Propelled Mast Lift
22 models · Every spec cited to source
